ZF KNX

ZF presents the world’s first wireless energy harvesting KNX light switch module that is configurable via ETS (from ETS5). The wireless light switch module is versatile and easy to integrate, creating significant freedom during the planning stage.

KNX-RF

With the ability to communicate without the need for a gateway, there are many potential applications, e.g. flexible room partitions in functional buildings, glass walls. The module is a self-sufficient and maintenance-free solution requiring no cabling and no batteries. Already in serial production, the wireless light switch module comes ready to install.

It is compatible with standard frames and panels for energy harvesting light switch modules and can also be combined with customer-specific designs and control panels. The actuation of the unit produces enough electrical energy to transmit a complete KNX-RF protocol in S-mode directly to any KNX-receiver.

For further information about the ETS5 compatability please read this article. You can find sources of supply for the KNX wireless light-switching module on our website on our KNX Distributor & Partner page

Our Distributors

KNX Manuals

KNX Datasheet
Quick Start Guide Switch Module
Quick Start Guide Media Coupler
Quick Start Guide Pairing Adapter
Technical Specification AFIM-1010
ZF KNX-RF Operating Manual

KNX Pushbutton FAQ’s

Which advantages are there for using the ZF KNX light switch module?

The energy harvesting pushbutton module from ZF directly supports the KNX RF radio protocol. Communication can be made with KNX radio receivers or KNX media coupler via the KNX RF protocol. There is no ‘Gateway’ necessary, to translate another radio protocol into a wired KNX Bus. Also, the ZF pushbutton module with the KNX media coupler can be configured with the ETS 5 Software. Parameters can be loaded via radio into the devices.

Which housing, panels or rockers can be used for KNX light switch module?

The ZF pushbutton module is compatible with all 55×55 design parts suitable for use with existing energy harvesting pushbuttons. If there are questions regarding the selection and procurement, please contact ZF.

How could the KNX push button module be configured via ETS?

You can configure the ZF KNX light switch module via ETS 5. The product can be selected via the ETS catalogue. In addition, ZF offers a catalogue file for download. There is the option to assign functions for light on/off, dim or shutter up/down. Parameters can be loaded via radio into the devices.

During the charging process – which takes a few seconds – the required energy is supplied by the specified battery adapter.

How many KNX devices can be connected?

Due to the KNX topology, one line can combine 255 switches and one media coupler.

Where can electricians and system integrators purchase the ZF KNX components?

For information on KNX distributors and partners, please visit the ZF Switches & Sensors Website: https://switches-sensors.zf.com/location-cat/knx-partner/
